AC DC Multi Voltage LED Driver Power Supply Single Switching With Overload Protection

Name: AC DC Multi Voltage LED Driver Power Supply Single Switching With Overload Protection
Brand: Meanwell
Price: 1 USD

Buy cheap AC DC Multi Voltage LED Driver Power Supply Single Switching With Overload Protection product

Brand Name : Meanwell

Model Number : LRS-100

Certification : CCC UL TUV CB EMC CE

Place of Origin : Guangzhou,Guangdong ,China

MOQ : 1pcs

Price : US $1-9 / Piece

Payment Terms : T/T, L/C, Western Union

Packaging Details : 0.34Kg ; 40pcs/14.6Kg/0.92CUFT

Efficiency : 85~91.5%

Output Power : 100W

Output Type : Single

Input Voltage : 85~264VAC,120~370VDC

Output Voltage : 5V/12V/15V/24V/36V/48VDC

Output Current : 18A/8.5A/7A/4.5A/2.8A/2.3A

The shell material : Metal

Warranty : 5 years

Demension : 129*97*30mm (L*W*H)

Working tempera : -40+85℃

Output Frequency : 50/60Hz

Contact Now

MEANWELL LRS-100-5 5V AC DC Multi Voltage Single Switching Power Supply

Features
1. Universal AC input
2. Withstand 300VAC surge input for 5 seconds
3. Withstand 5G vibration test
4. Most economical models with safety certificates
5. Protections: over current/overload/short circuit
6. No load power consumption: 0.2W~0.75W
7. Ultra compact and 1U low profile
8. Operating altitude up to 5000 meters
9. Compliance to IEC/EN60335-1(PD3) and IEC/EN61558-1, -2-16 for household

Description
Mean Well LRS Family AC/DC Power Supplies are single-output enclosed type power supplies with 30mm of low profile design. LRS series will be the 2016’s most popular item. The entire series provides an output voltage of 3.3V, 4.2V, 5V, 12V, 15V, 24V, 36V, and 48V. The LRS Family delivers an extremely low no load power consumption and allows the end system to easily meet the worldwide energy requirement. They have a range of protection functions and 5G anti-vibration capability and complies with international safety regulations and serve as a high price-to-performance power supply solution for various industrial applications. LRS series led driver applications for ndustrial automation machinery, industrial control system, mechanical and electrical equipment, electronics instruments, equipments or apparatus, household appliances.

Power Supply PARM

MODEL		LRS-100-5	LRS-100-12	LRS-100-15	LRS-100-24	LRS-100-48
OUTPUT	DC VOLTAGE	5V	12V	15V	24V	48V
	RATED CURRENT	18A	8.5A	7A	4.5A	2.3A
	CURRENT RANGE	0 〜18A	0 〜8.5A	0 ~ 7A	0 ~ 4.5A	0 ~ 2.3A
	RATED POWER	90W	102W	105W	108W	110.4W
	RIPPLE & NOISE (max.)	100mVp-p	120mVp-p	120mVp-p	150mVp-p	200mVp-p
	VOLTAGE ADJ. RANGE	4.5 - 5.5V	10.2 - 13.8V	13.5 -18V	21.6 - 28.8V	43.2 - 52.8V
	VOLTAGE TOLERANCE	±2.0%	±1.0%	± 1.0%	± 1.0%	± 1.0%
	LINE REGULATION	±0.5%	±0.5%	± 0.5%	± 0.5%	±0.5%
	LOAD REGULATION	± 1.0%	±0.5%	± 0.5%	± 0.5%	±0.5%
	SETUP, RISE TIME	500ms, 30ms/230VAC 500ms,30ms/115VAC at full load
	SETUP, RISE TIME

MODEL		LRS-100-5	LRS-100-12	LRS-100-15	LRS-100-24	LRS-100-48
INPUT	VOLTAGE RANGE	85 ~ 264VAC 120 -373VDC (Withstand 300VAC surge for 5sec. Without damage)
	FREQUENCY RANGE	47 ~ 63Hz
	EFFICIENCY (Typ.)	86%	88%	88.5%	90%	91%
	AC CURRENT	1.9A/115VAC 1.2A/230VAC
	INRUSH CURRENT (max.)	COLD START 50A/230VAC
	LEAKAGE CURRENT	<0.75mA/ 240VAC

PROTECTION

MODEL

LRS-100-5

LRS-100-12

LRS-100-15

LRS-100-24

LRS-100-48

OVERLOAD

110~150% rated output power

OVER VOLTAGE

Protection type : Constant current limiting, recovers automatically after fault condition is removed

SAFETY &EMC
(Note 9)

SAFETY STANDARDS

UL60950-1,TUV EN60950-1, EN60335-1, EN61558-1/-2-16,CCC GB4943approved

WITHSTAND VOLTAGE

I/P-O/P:3.75KVAC

ISOLATION RESISTANCE

I/P-O/P, I/P-FG, 0/P-FG:100M Ohms / 500VDC / 25°C/ 70% RH

EMC EMISSION

Compliance to EN55022 (CISPR22), GB9254 Class B, EN55014, EN61000-3-2,-3

EMC IMMUNITY

Compliance to EN61000-4-2,3,4,5,6,8,11, EN61000-6-2 (EN50082-2), heavy industry level, criteriaA

ENVIRONMENT

WORKING TEMP.

-30 〜+70°C (Refer to "Derating Curve")

WORKING HUMIDITY

20 〜90% RH non-condensing

STORAGE TEMP., HUMIDITY

-40 ~ +85°C, 10 ~ 95% RH

TEMP. COEFFICIENT

±0.03%/C (0 〜50C)

AC DC Multi Voltage LED Driver Power Supply Single Switching With Overload Protection

Packaging & Delivery

Packaging Details
Packing:0.34Kg ; 40pcs/14.6Kg/0.92CUFT
Delivery Time
Shipped in 5 days after payment
